| This device is mainly applied in the system of dispenser to remove the solid sedimentation is the oil ,ensuring the cleaning of the oil or like ,and as a result to extend the life span and accuracy of the flow meter. In the system of dispenser ,it is fixed between the oil pump and the flow meter. |
|
| Materials: |
| Body: |
Body: Aluminum (Spray-Painted) |
| Seals: |
Buna-N |
|
| Technical Specifications: |
 |
Working pressure:0.2Mpa |
|
Filter accuracy:30um |
|
Flow Rate:65L/min |
|
Rating Medium:Gasoline,Kerosene, Diesel |
|
100% Factory Tested. |
|
| Package: |
| Product ID |
Net Weight |
Cross Weight |
Dimension |
| U103-A |
2kg/case of1 |
2.2kg/case of1 |
20x13x14cm/case of1 |
|
| Ordering Specifications: |
| Product ID |
Product Name |
| U103-A |
Filter |
| U103-A2 |
Filter with Filter Screen |
|
